PVS-14R (Rugged) - NNVT GEN 2

Steele Industries PVS-14R Night Vision Monocular

Optical Performance

• Magnification: 1x
• Field of View: 40 Degrees
• Focus Range: 9.8" To Infinity
• Diopter Adjustment: -6 To +2
• Eye Relief: 25MM (Standard Mil-spec Options)

Optics Compatibility: Fully compatible with PVS-14 Style Eyepieces & Objectives

Physical Specs

• Dimensions: 4.5"L x 2.25"H x 2.0"W
• Weight: 310g (Standard Mil-spec Optics)
• Housing Material: Machined 7075-T6 Aluminum construction for increased structural rigidity and durability
• Environmental Rating: Submersible To 66FT
• Intensifier Tube Compatibility: Compatible With MX-11769 & MX-10160 style tubes

Power Specs

• Primary Power Source: (1) CR123 Size Battery
• Operation Time: Approximately 50 Hours on a single Lithium Battery
• External Power: Integrated FISCHER port for connection to remote external battery packs to extend field runtime
• Reverse Polarity: "No-fail" design allows the battery to be inserted in either orientation for power
• Manual Gain Control: Allows the user to manually adjust image brightness for optimal clarity in varying light levels
• Indicators: Integrated IR LED and Low Battery indicators

Key Features

• Onboard IR Illuminator: Built-in for use in zero-light environments
• High Light Shut Off: Protects the intensifier tube from damage in high-light conditions
• Rigid Evolution: Machined aluminum housing is actually lighter than traditional plastic PVS-14 housings while being significantly stronger
• Accessory Compatibility: Retains full compatibility with all existing PVS-14 mounts and accessories

Warranty: Lifetime "no questions asked" housing warranty
